Nemotron 3 Nano Omni

Run these steps on Jetson Thor. Set paths for the TensorRT Edge-LLM checkout, model checkpoint, ONNX export directory, and engine output directory:

export TRT_EDGE_LLM_REPO=$HOME/tensorrt-edge-llm
export CHECKPOINT_DIR=/path/to/nemotron-nano-3-omni-checkpoint
export WORKSPACE=$HOME/tensorrt-edgellm-workspace/nemotron-nano-3-omni
export ONNX=$WORKSPACE/onnx
export ENGINE=$WORKSPACE/engines

Build TensorRT Edge-LLM

cd $HOME
git clone https://github.com/NVIDIA/TensorRT-Edge-LLM.git tensorrt-edge-llm
cd tensorrt-edge-llm
git submodule update --init 3rdParty/nlohmannJson 3rdParty/NVTX

mkdir -p build
cd build
export PATH=/usr/local/cuda/bin:$PATH

cmake .. -DCMAKE_BUILD_TYPE=Release \
  -DENABLE_CUTE_DSL=ALL \
  -DTRT_PACKAGE_DIR=/usr \
  -DCUDA_CTK_VERSION=13.0

make -j$(nproc)

Export ONNX

export PYTHONPATH=$TRT_EDGE_LLM_REPO/experimental:$PYTHONPATH
python3 -m venv $HOME/trt-edgellm-venv
source $HOME/trt-edgellm-venv/bin/activate

cd $TRT_EDGE_LLM_REPO/experimental/llm_loader
pip3 install -r requirements.txt

python3 -m llm_loader.export_all_cli \
  $CHECKPOINT_DIR \
  $ONNX

This creates $ONNX/llm, $ONNX/visual, and $ONNX/audio.

Build Engines

export BUILD=$HOME/tensorrt-edge-llm/build
export EDGELLM_PLUGIN_PATH=$BUILD/libNvInfer_edgellm_plugin.so
export LD_PRELOAD=$EDGELLM_PLUGIN_PATH

$BUILD/examples/llm/llm_build \
  --onnxDir $ONNX/llm \
  --engineDir $ENGINE/llm

$BUILD/examples/multimodal/visual_build \
  --onnxDir $ONNX/visual \
  --engineDir $ENGINE/visual

$BUILD/examples/multimodal/audio_build \
  --onnxDir $ONNX/audio \
  --engineDir $ENGINE/audio

# Some builder versions emit nested modality directories. Flatten them if needed.
[ -d "$ENGINE/visual/visual" ] && mv $ENGINE/visual/visual/* $ENGINE/visual/ && rmdir $ENGINE/visual/visual
[ -d "$ENGINE/audio/audio" ] && mv $ENGINE/audio/audio/* $ENGINE/audio/ && rmdir $ENGINE/audio/audio

Run Inference

Use the same inference command for text, vision, and audio by changing the input and output JSON files:

$BUILD/examples/llm/llm_inference \
  --engineDir $ENGINE/llm \
  --multimodalEngineDir $ENGINE \
  --inputFile <input.json> \
  --outputFile <output.json> \
  --dumpOutput

Text input:

{
  "requests": [
    {
      "messages": [
        {"role": "user", "content": "What is 2+2?"}
      ],
      "max_generate_length": 50,
      "temperature": 0.0
    }
  ]
}

Vision input:

{
  "requests": [
    {
      "messages": [
        {
          "role": "user",
          "content": [
            {"type": "image", "image": "/path/to/image.jpg"},
            {"type": "text", "text": "What do you see in this image?"}
          ]
        }
      ],
      "max_generate_length": 100,
      "temperature": 0.0
    }
  ]
}

Audio input uses a pre-computed mel-spectrogram .safetensors file shaped [1, time_steps, 128] with float16 values:

{
  "requests": [
    {
      "messages": [
        {
          "role": "user",
          "content": [
            {"type": "audio", "audio": "/path/to/audio_mel.safetensors"},
            {"type": "text", "text": "What did you hear in this audio?"}
          ]
        }
      ],
      "max_generate_length": 100,
      "temperature": 0.0
    }
  ]
}
