TensorRT Edge-LLM on Jetson

TensorRT Edge-LLM is NVIDIA’s high-performance C++ inference runtime for LLMs and VLMs on embedded platforms. The workflow compiles trained models into optimized TensorRT engines; at run time, a small native binary loads those engines and serves requests with no Python interpreter in the inference path. Quantization (INT4, NVFP4, FP8) reduces weight footprint so larger models remain practical on memory-constrained devices. The SDK supports a wide range of models; see the full Supported Models list.

Overview

Edge-LLM supports a wide range of LLMs and VLMs across the entire Jetson family, from Orin Nano to Thor. See the full Supported Models list. In this tutorial, we walk through two examples that showcase the spectrum:

The workflow:

1. Step 1: Export models (Python, x86 or Thor). Quantize and convert HuggingFace models to portable ONNX files. Transfer them to your target Jetson(s).
2. Step 2: Build the C++ runtime (each Jetson). Clone the repo, compile the C++ engine builder and inference binary. TensorRT engines are hardware-specific and must be built on the device that will run them.
3. Step 3: Cosmos Reason2 8B on Thor (NVFP4). Build engines and run VLM inference on Jetson Thor.
4. Step 4: Qwen3-4B-Instruct on Orin Nano (INT4 AWQ). Build engines and run LLM inference on Jetson Orin Nano 8 GB.

Prerequisites

x86 Host / Jetson Thor (for Step 1: Model Export)

Jetson Target Device (for Step 2: Build and Inference)

Quantization and Platform Compatibility

Step 1: Export Models (x86 Host or Jetson Thor)

This step converts HuggingFace models to quantized ONNX files. It requires significant GPU memory and Python, so it runs on either an x86 workstation or Jetson Thor, not on Orin devices.

• x86 workstation: use this if you have a Linux PC or cloud GPU. After export, transfer the ONNX files to your Jetson.
• Jetson Thor: run the export directly on Thor using the NVIDIA PyTorch container. No separate PC needed.

1.1 Set Up the Environment

docker pull nvcr.io/nvidia/pytorch:25.12-py3

docker run -it --runtime nvidia \
    --name edgellm-export \
    -v $(pwd):/workspace \
    -w /workspace \
    nvcr.io/nvidia/pytorch:25.12-py3 \
    bash

git clone https://github.com/NVIDIA/TensorRT-Edge-LLM.git
cd TensorRT-Edge-LLM
git submodule update --init --recursive

python3 -m venv --system-site-packages venv
source venv/bin/activate

pip3 install --no-deps .
sed '/^torch/d' requirements.txt > /tmp/reqs.txt
pip3 install -r /tmp/reqs.txt

export WORKSPACE_DIR=/workspace/tensorrt-edgellm-workspace

docker pull nvcr.io/nvidia/pytorch:25.12-py3

docker run --gpus all -it \
    --name edgellm-export \
    -v $(pwd):/workspace \
    -w /workspace \
    nvcr.io/nvidia/pytorch:25.12-py3 \
    bash

git clone https://github.com/NVIDIA/TensorRT-Edge-LLM.git
cd TensorRT-Edge-LLM
git submodule update --init --recursive

python3 -m venv venv
source venv/bin/activate
pip3 install .

git clone https://github.com/NVIDIA/TensorRT-Edge-LLM.git
cd TensorRT-Edge-LLM
git submodule update --init --recursive

python3 -m venv venv
source venv/bin/activate
pip3 install .

1.2 Verify Installation

tensorrt-edgellm-export-llm --help
tensorrt-edgellm-quantize-llm --help

Both commands should print their usage information without errors.

1.3 Log in to HuggingFace

Cosmos-Reason2-8B is a gated model: you must accept the license and authenticate before downloading.

1. Visit nvidia/Cosmos-Reason2-8B on HuggingFace and click “Agree and access repository”.
2. Generate a token at HuggingFace Settings - Tokens (read access is sufficient).
3. Log in from the terminal:

huggingface-cli login

Paste your token when prompted. This persists across sessions inside the container.

1.4 Export Cosmos-Reason2-8B (VLM)

Cosmos Reason2 is a vision-language model, so you need to export two components: the language model and the visual encoder.

# Thor Docker users: WORKSPACE_DIR was already set to /workspace/tensorrt-edgellm-workspace in Step 1.1
# x86 / venv users: set it now
export WORKSPACE_DIR=${WORKSPACE_DIR:-$HOME/tensorrt-edgellm-workspace}
export MODEL_NAME=Cosmos-Reason2-8B
mkdir -p $WORKSPACE_DIR && cd $WORKSPACE_DIR

Quantize the Language Model

tensorrt-edgellm-quantize-llm \
    --model_dir nvidia/Cosmos-Reason2-8B \
    --output_dir $MODEL_NAME/quantized \
    --quantization nvfp4

tensorrt-edgellm-quantize-llm \
    --model_dir nvidia/Cosmos-Reason2-8B \
    --output_dir $MODEL_NAME/quantized \
    --quantization int4_awq

tensorrt-edgellm-quantize-llm \
    --model_dir nvidia/Cosmos-Reason2-8B \
    --output_dir $MODEL_NAME/quantized \
    --quantization fp8

Export Language Model to ONNX

tensorrt-edgellm-export-llm \
    --model_dir $MODEL_NAME/quantized \
    --output_dir $MODEL_NAME/onnx/llm

Export Visual Encoder to ONNX

The visual encoder is exported from the original (unquantized) model directory:

tensorrt-edgellm-export-visual \
    --model_dir nvidia/Cosmos-Reason2-8B \
    --output_dir $MODEL_NAME/onnx/visual

1.5 Export Qwen3-4B-Instruct (LLM)

Qwen3-4B-Instruct is a text-only LLM. It supports INT4 AWQ, which brings the 4B model down to ~2 GB of weights, a comfortable fit for Orin Nano’s 8 GB unified memory. No HuggingFace login is needed (Apache 2.0 license).

# Thor Docker users: WORKSPACE_DIR was already set to /workspace/tensorrt-edgellm-workspace in Step 1.1
# x86 / venv users: set it now
export WORKSPACE_DIR=${WORKSPACE_DIR:-$HOME/tensorrt-edgellm-workspace}
export MODEL_NAME=Qwen3-4B-Instruct
mkdir -p $WORKSPACE_DIR && cd $WORKSPACE_DIR

Quantize and Export

tensorrt-edgellm-quantize-llm \
    --model_dir Qwen/Qwen3-4B-Instruct-2507 \
    --output_dir $MODEL_NAME/quantized \
    --quantization int4_awq

tensorrt-edgellm-export-llm \
    --model_dir $MODEL_NAME/quantized \
    --output_dir $MODEL_NAME/onnx

tensorrt-edgellm-quantize-llm \
    --model_dir Qwen/Qwen3-4B-Instruct-2507 \
    --output_dir $MODEL_NAME/quantized \
    --quantization fp8

tensorrt-edgellm-export-llm \
    --model_dir $MODEL_NAME/quantized \
    --output_dir $MODEL_NAME/onnx

tensorrt-edgellm-quantize-llm \
    --model_dir Qwen/Qwen3-4B-Instruct-2507 \
    --output_dir $MODEL_NAME/quantized \
    --quantization nvfp4

tensorrt-edgellm-export-llm \
    --model_dir $MODEL_NAME/quantized \
    --output_dir $MODEL_NAME/onnx

1.6 Transfer ONNX Files to Jetson

ONNX from Step 1 sits on whatever machine ran the export (your x86 workstation or Jetson Thor). Copy each model’s ONNX folder only onto the Jetson that will build engines for that model: Cosmos Reason2 8B on Thor, Qwen3-4B-Instruct on Orin Nano.

Exported on x86? Use both scp blocks below. Exported on Thor? Use only the Orin Nano block for Qwen3.

To Jetson Thor (Cosmos-Reason2-8B ONNX):

scp -r Cosmos-Reason2-8B/onnx <user>@<thor-ip>:~/tensorrt-edgellm-workspace/Cosmos-Reason2-8B/

To Jetson Orin Nano (Qwen3-4B-Instruct ONNX):

scp -r Qwen3-4B-Instruct/onnx <user>@<orin-nano-ip>:~/tensorrt-edgellm-workspace/Qwen3-4B-Instruct/

Create the target directories first if they do not exist:

ssh <user>@<thor-ip> "mkdir -p ~/tensorrt-edgellm-workspace/Cosmos-Reason2-8B"
ssh <user>@<orin-nano-ip> "mkdir -p ~/tensorrt-edgellm-workspace/Qwen3-4B-Instruct"

If you followed this tutorial’s Docker instructions (which set WORKSPACE_DIR under /workspace/), the ONNX files are already on the host and no extra copy step is needed.

Step 2: Build the C++ Runtime on Your Jetson

Everything from here forward runs on the target Jetson device and is pure C++; no Python needed. Run steps 2.1–2.5 on your target device, then follow the section for your device:

sudo chown -R $(whoami):$(whoami) tensorrt-edgellm-workspace

2.1 Install Build Dependencies

sudo apt update
sudo apt install -y cmake build-essential git \
    cuda-toolkit-13-0 \
    libnvinfer-headers-dev libnvinfer-dev libnvonnxparsers-dev
export PATH=/usr/local/cuda/bin:$PATH

sudo apt update
sudo apt install -y cmake build-essential git \
    cuda-toolkit-12-6 \
    libnvinfer-headers-dev libnvinfer-dev libnvonnxparsers-dev
export PATH=/usr/local/cuda/bin:$PATH

Verify nvcc is available:

nvcc --version

2.2 Clone the Repository

cd ~
git clone https://github.com/NVIDIA/TensorRT-Edge-LLM.git
cd TensorRT-Edge-LLM
git submodule update --init --recursive

2.3 Configure and Build

If you previously ran Docker with a volume mount into this repo, fix file ownership first:

sudo chown -R $(whoami):$(whoami) ~/TensorRT-Edge-LLM

cd ~/TensorRT-Edge-LLM
rm -rf build
mkdir build && cd build

cmake .. \
    -DCMAKE_BUILD_TYPE=Release \
    -DTRT_PACKAGE_DIR=/usr \
    -DCMAKE_TOOLCHAIN_FILE=cmake/aarch64_linux_toolchain.cmake \
    -DEMBEDDED_TARGET=jetson-thor

make -j$(nproc)

cd ~/TensorRT-Edge-LLM
rm -rf build
mkdir build && cd build

cmake .. \
    -DCMAKE_BUILD_TYPE=Release \
    -DTRT_PACKAGE_DIR=/usr \
    -DCMAKE_TOOLCHAIN_FILE=cmake/aarch64_linux_toolchain.cmake \
    -DEMBEDDED_TARGET=jetson-orin

make -j$(nproc)

2.4 Verify the Build

cd ~/TensorRT-Edge-LLM
./build/examples/llm/llm_build --help
./build/examples/llm/llm_inference --help

2.5 Set Up Environment Variables

The EDGELLM_PLUGIN_PATH variable tells the runtime where to find the Edge-LLM custom TensorRT plugins (AttentionPlugin, Int4GemmPlugin, etc.):

cd ~/TensorRT-Edge-LLM
export EDGELLM_PLUGIN_PATH=$(pwd)/build/libNvInfer_edgellm_plugin.so
export WORKSPACE_DIR=$HOME/tensorrt-edgellm-workspace

Choose Your Deployment Path

After completing Step 2, follow the section that matches your device. Steps 3 and 4 below are worked examples, but the same workflow applies to any Jetson (AGX Orin, Orin NX, etc.) with any supported model, as long as the model fits in memory and you use a quantization format your GPU supports (see the precision table above).

Step 3: Cosmos Reason2 8B on Jetson Thor (NVFP4)

3.1 Build the Language Model Engine

export MODEL_NAME=Cosmos-Reason2-8B

./build/examples/llm/llm_build \
    --onnxDir $WORKSPACE_DIR/$MODEL_NAME/onnx/llm \
    --engineDir $WORKSPACE_DIR/$MODEL_NAME/engine/llm \
    --maxBatchSize 1 \
    --maxInputLen 1024 \
    --maxKVCacheCapacity 4096

3.2 Build the Visual Encoder Engine

./build/examples/multimodal/visual_build \
    --onnxDir $WORKSPACE_DIR/$MODEL_NAME/onnx/visual \
    --engineDir $WORKSPACE_DIR/$MODEL_NAME/engine

The visual engine is saved to $WORKSPACE_DIR/$MODEL_NAME/engine/visual/.

3.3 Create an Input File

Save the following as $WORKSPACE_DIR/input_vlm.json. Use an absolute path for the image:

cat > $WORKSPACE_DIR/input_vlm.json << 'EOF'
{
    "batch_size": 1,
    "temperature": 1.0,
    "top_p": 1.0,
    "top_k": 50,
    "max_generate_length": 128,
    "requests": [
        {
            "messages": [
                {
                    "role": "user",
                    "content": [
                        {
                            "type": "image",
                            "image": "IMAGE_PATH_PLACEHOLDER"
                        },
                        {
                            "type": "text",
                            "text": "Describe what you see in this image."
                        }
                    ]
                }
            ]
        }
    ]
}
EOF

Then replace the image path placeholder with a real image (the repo ships sample images):

sed -i "s|IMAGE_PATH_PLACEHOLDER|$(pwd)/examples/multimodal/pics/red_panda.jpeg|" \
    $WORKSPACE_DIR/input_vlm.json

3.4 Run Inference

./build/examples/llm/llm_inference \
    --engineDir $WORKSPACE_DIR/$MODEL_NAME/engine/llm \
    --multimodalEngineDir $WORKSPACE_DIR/$MODEL_NAME/engine \
    --inputFile $WORKSPACE_DIR/input_vlm.json \
    --outputFile $WORKSPACE_DIR/output_vlm.json \
    --dumpOutput

3.5 Verify Output

cat $WORKSPACE_DIR/output_vlm.json

Step 4: Qwen3-4B-Instruct on Jetson Orin Nano 8 GB (INT4 AWQ)

4.1 Build the Engine

The memory-optimized parameters below are tuned for Orin Nano 8 GB. If you hit CUDA out of memory during the build, reduce the limits further (e.g. --maxInputLen 256 --maxKVCacheCapacity 512) and free system memory first:

sudo sysctl -w vm.drop_caches=3

export MODEL_NAME=Qwen3-4B-Instruct

./build/examples/llm/llm_build \
    --onnxDir $WORKSPACE_DIR/$MODEL_NAME/onnx \
    --engineDir $WORKSPACE_DIR/$MODEL_NAME/engine \
    --maxBatchSize 1 \
    --maxInputLen 512 \
    --maxKVCacheCapacity 1024

4.2 Create an Input File

cat > $WORKSPACE_DIR/input_qwen.json << 'EOF'
{
    "batch_size": 1,
    "temperature": 1.0,
    "top_p": 1.0,
    "top_k": 50,
    "max_generate_length": 512,
    "requests": [
        {
            "messages": [
                {
                    "role": "user",
                    "content": "What are the benefits of running AI models on edge devices like NVIDIA Jetson?"
                }
            ]
        }
    ]
}
EOF

4.3 Run Inference

./build/examples/llm/llm_inference \
    --engineDir $WORKSPACE_DIR/$MODEL_NAME/engine \
    --inputFile $WORKSPACE_DIR/input_qwen.json \
    --outputFile $WORKSPACE_DIR/output_qwen.json \
    --dumpOutput

4.4 Verify Output

cat $WORKSPACE_DIR/output_qwen.json

Integrating Edge-LLM in Your C++ Application

The llm_inference binary used above is a reference application. For production use (robotics, camera apps, industrial inspection, kiosks), you integrate Edge-LLM directly via the C++ API. The API surface is three calls: create a runtime, capture CUDA graphs, then call handleRequest() per query. See the C++ runtime headers and example application on GitHub.

Troubleshooting

References

• TensorRT Edge-LLM GitHub
• Supported Models on TensorRT Edge-LLM
• Official TensorRT Edge-LLM Documentation
• Hackster.io: Getting Started with TensorRT Edge-LLM on Jetson Thor
